Khoom Description
Qhov no SAW H beam vuam tshuab yog hom gantry, upright kem thiab sab sauv platform yog ua los ntawm lub teb chaws tus qauv profiles kom tsis txhob deformation los ntawm kev ntxhov siab los ntawm ntau tshaj vuam seams ntawm daim hlau, kom ntseeg tau tias muaj kev ruaj ntseg thiab txhim khu kev qha lag luam ntawm cov cuab yeej thiab lub neej ntev kev pab cuam.
Muaj cov log tsheb taug kev ntawm ob qho kawg ntawm ib sab ntawm txoj kab taug kev kawg, thiab cov log tsheb tau hloov kho los ntawm cov ncej eccentric los nias cov lus qhia kev tsheb ciav hlau los qhia, uas ua kom ruaj khov thiab nyab xeeb khiav ceev ntawm tus ncej.
Standard rail dav yog 5 meters, thiab ntev yog 18 meters (24kg / m rail thiab siab phaj thiab lwm yam accessories yog muab los ntawm tus neeg muas zaub), thiab zoo vuam stroke yog 15 meters.
Peb tuaj yeem ua H beam tsis siv neeg vuam tshuab rau koj raws li koj qhov kev thov beam.
Ua tau zoo taug qab cov welds nyob rau lub sijhawm tiag tiag thiab txo qis kev hloov kho ntau zaus rau cov phom vuam vim kev ua haujlwm deformation thaum lub sijhawm SAW vuam.
Lub tshuab caij nplooj ntoos hlav ntxiv rau saum lub arc qhia thav duab, thiab ob qho tib si txuas nrog kom ntseeg tau tias plaub lub log qhia tuaj yeem ua rau cov hlau vuam profile thaum vuam deformed, thiab tib lub sijhawm tuaj yeem nce qhov vuam ntawm qhov sib txawv ntawm qhov sib txawv. seem beam (tsis muaj cov cuab yeej zoo li no los ntawm lwm tus neeg muag khoom).
Lus Cim: Peb H beam Submerged arc steel vuam tshuab yog nruab nrog ib khub ntawm H-shaped steel arc qhia thav duab thiab ib khub ntawm lub thawv-shaped beam qhia arc ncej. Los ntawm kev hloov lub arc qhia ncej, ob qho tib si H-zoo li tus steel workpieces (cross kab) thiab lub thawv beam workpieces yuav welded yam tsis muaj dismantling.
Khoom Parameters
Yam khoom | Tus nqi |
Gantry ntsuas | 5000 hli |
Khiav ntev | 18000mm, Zoo vuam stroke 15000mm (24kg phau ntawv qhia kev tsheb nqaj hlau, siab phaj thiab cov khoom siv sib txuas yog muab los ntawm tus neeg siv khoom) |
Siv tau H-shaped steel tis phaj dav | 140-800 hli |
Siv tau H-beam web qhov siab | 160-2000 hli |
Siv tau workpiece ntev | 4000-15000mm |
H-beam vuam txoj hauj lwm | Nkoj welding (tuaj yeem welded rov qab thiab tawm) |
Siv tau cross kem workpiece loj | Qhib qhov tsawg kawg nkaus: 150mm, qhov tob 500mm |
Siv tau lub thawv beam workpiece seem loj | 300-1200mm(Xav tau hloov lub thawv beam qhia arc ncej vuam) |
Siv tau workpiece ntev | 4000-15000mm |
Box beam welding txoj hauj lwm | Plane V-groove vuam |
Cua siab | 0. |
Mast txav ceev | 240 ~ 2400mm / min (Raws li qhov siab ntawm lub vuam lub kaum sab xis ntawm lub workpiece, xaiv txoj kab uas hla ntawm vuam hlau, xaiv cov txheej txheem vuam tsim nyog, thiab txiav txim siab qhov vuam ceev) |
Rov qab ceev | 3m / min |
Vuam hlau loj | φ4-φ5 hli |
Qhov hnyav ntawm cov hlau reel bracket | 50-250kg |
Flux rov qab tshuab | 50kg x 2 |
Tag nrho lub peev xwm nruab | Lub cev muaj zog: 9.7 kW Vuam tshuab fais fab: ib ncig ntawm 100 kVA × 2 |
Hwj chim | 3 theem AC 380V 50Hz |
Ua haujlwm ib puag ncig | Nyob sab hauv tsev kub: 0 degree -45 degree , txheeb ze humidity Tsawg dua los yog sib npaug li 90% (tsis-condensing) |
Khoom duab
Lwm cov kab tshuab
CNC Plasma txiav
H beam Assembly
H beam Flange ncaj nraim
Xaus ntsej muag milling tshuab
FAQ
1.Q: Koj puas yog lub Hoobkas lossis tuam txhab lag luam?
A: Peb yog lub Hoobkas.
2. Q: Koj cov nqe lus them nqi yog dab tsi?
A: Peb txhawb T / T, L / C, Western Union thiab lwm yam. Lwm txoj hauv kev kuj tuaj yeem tau txais tom qab peb ob tog sib tham thiab pom zoo. Lwm cov lus nug hu rau peb ncaj qha!
3. Q: Yuav ua li cas txog lub warranty?
A: Muaj 12 lub hlis rau lub warranty.
Thaum lub warranty tsis muaj lub luag haujlwm rau cov tawg los ntawm kev ua phem
4.Q: Koj lub Hoobkas nyob qhov twg? Kuv tuaj yeem mus saib tau li cas?
A: Peb lub Hoobkas nyob hauv Jiangsu Wuxi (nrog rau Shanghai), Tuam Tshoj.Koj tuaj yeem ya mus rau Shanghai tshav dav hlau ncaj qha.Tag nrho peb cov neeg siv khoom, los ntawm tsev lossis txawv teb chaws, zoo siab tos txais tuaj xyuas peb!
5.Q: Koj puas tau xa tawm mus rau qhov twg?
A: Peb tau xa tawm mus rau Is Nrias teb, Russia, Tebchaws Asmeskas, UK, Kuwait, Oman, Pakistan, South Africa, Bulgaria, Egypt, Nyab Laj, thiab lwm yam.
6.Q: Yuav ua li cas rau nruab lub tshuab?
A: Raws li ib txwm muaj, peb tus kws tshaj lij yuav mus rau koj cov nroj tsuag los txhim kho lub tshuab thiab cob qhia koj cov neeg ua haujlwm tom qab cov tshuab tuaj txog koj cov nroj tsuag. Feem ntau 1engineer 5-7hnub yog OK.
Yog tias koj muaj engineers thiab tsis xav tau peb mus, peb tuaj yeem xa koj lub hauv paus tshuab kos duab, hluav taws xob kos duab thiab phau ntawv qhia rau koj, yuav koom tes nrog koj zoo heev.
7.Q: Koj puas tuaj yeem ua tshuab OEM?
A: Yog, peb tuaj yeem ua tau. Tom qab tshuab tiav, peb tuaj yeem muab koj lub lable rau nws raws li qhov koj xav tau los pab koj kom tau txais kev txiav txim tshiab ntxiv.
Cov neeg siv khoom xav tau, thov koj xav tiv tauj peb!
