Eccentric Nres 28mm rau Vuam Fixture Rooj
--Tsis txhob kwv yees. Txhob swb. Xauv koj workpiece hauv vib nas this nrog 1/4 tig.--
Cov khoom no yog dab tsi?
Cov28mm Eccentric nresyog ib qho hnyav - lub luag haujlwm tso tseg nres tsim los rau vuam rooj nrog 28mm boreholes (16mm lossis 28mm qhov xaiv muaj). Tsis zoo li tus qauv puag ncig nres, eccentric cam mechanism tso cai rau koj kaw qhov nres kom ruaj khov rau qhov chaw ua haujlwm - tsis muaj cuab yeej, tsis muaj hammering, tsis muaj slipping.
Zoo tagnrho rau:
★ Vuam rooj fixturing
★ Sib dhos kab positioning
★Repeatable batch ua hauj lwm
★ Kev hloov pauv sai ntawm qhov ntau thiab tsawg
Khoom Parameters
| Parameter | Tus nqi |
| Mounting Txoj kab uas hla | 28mm (g6 kam rau ua, precision haum) |
| Eccentricity | 0.5mm / 0.75mm / 1.0mm (yeem) |
| Qhov siab | 25mm (qhov loj me) |
| Khoom siv | 45 # Hlau / 40Cr (qib hwm) |
| Hardness | HRC 45-50 (nto hardened) |
| Nto tiav | Dub oxide / Zinc plated / Chrome plated |
| Hom kev ua haujlwm | Knurled phau ntawv / Hex yuam sij / Nrog kov |
Cov Khoom Zoo
Cov yam ntxwv tseem ceeb - Vim li cas koj xav tau qhov no
⚡ 1/4 Tig Locking Action
Ntxig rau hauv ib qho 28mm lub rooj qhov. Tig lub kov 90 degree. Lub eccentric cam expands tawm tsam lub qhov phab ntsa - instant tuav. Tsis muaj screws, tsis muaj wrenches.
🔒 Zero Wobble, Zero Shift
Concentric nres cia siab rau kev sib txhuam ib leeg. Lub eccentric nres tsim ib tug neeg kho tshuab xauv. Txawm tias nyob rau hauv hammering los yog hnyav clamping, nws nyob raws nraim qhov koj muab nws.
🛠️ Dual Siv - Nres & Clamp Txhawb
Siv raws li ib qho nyuaj nres rau workpiece ntug alignment, los yog raws li ib tug backstop rau ib tug toggle clamp. Lub ntsej muag tiaj tus muab qhov tseeb 90℃siv qhov chaw.
📏 Precision Ground Contact Face
Lub ntsej muag nres yog nto - hauv av rau ± 0.1mm perpendicularity. Koj qhov chaw rov ua dua tau zoo dua.
🧲 Xaiv Magnetic Base Version
Xav tau txhais tes- rov tso dua dawb? Xaiv qhov sib nqus puag ncig - tuav rau lub rooj steel, tsis muaj qhov yuav tsum tau.
Cov khoom siv
| Kev lag luam | Siv Case |
|---|---|
| Vuam fabrication | Positioning repeatable weldments |
| Cov kab sib dhos | Ceev nres rau ib feem indexing |
| CNC / router rooj | Lub laj kab nres rau daim ntawv cov khoom |
| Kev tshuaj xyuas | Nrhiav tus pin rau check fixtures |
| Kev kawm | Kev qhia rov ua dua tshiab |
► Peb tuaj yeem txais customized, yog tias koj muaj kev tshwj xeeb, thov koj xav tias dawb rau DM peb tus kws muag khoom muag:Eva lub caij ntuj sov
Khoom Installation
Yuav Siv Li Cas (30-Second Setup)?
1.Ntxig - Tso lub nres rau hauv ib qho 28mm qhov ntawm koj lub rooj vuam.
2.Align - Xaub koj workpiece tiv thaiv lub ntsej muag tiaj tus.
3.Xauv – Tig tus kov 90℃clockwise.
4.Ua haujlwm - Clamp, vuam, rauj - nres yuav tsis txav.
Hook: 4 kauj ruam. 3 vib nas this. 1,000 rov ua dua yam tsis muaj kev hloov kho.
FAQ
Yog xav paub ntxiv, hu rau peb tus kws muag khoom muag:Eva lub caij ntuj sovncaj qha.
01.Qhov no puas haum kuv 28mm qhov vuam rooj?
02.Lub ntsuas phoo muaj zog npaum li cas?
03.Kuv tuaj yeem kho lub ntsej muag qhov siab?
04.Nws puas tuaj yeem siv rau ntawm cov rooj vuam stainless hlau?
05.Does lub hauv paus hlau nplaum hloov lub qhov xauv?
Tau txais Daim Ntawv Tso Cai rau peb Eccentric Nres 28mm rau Vuam Fixture Rooj
